[RT5R] Dual Band HAM Radio

Name: [RT5R] Dual Band HAM Radio
Brand: Retevis
SKU: A7105A
Price: 41.0 USD
Availability: OutOfStock

RetevisSKU: A7105A

Title: Single Unit

Variant

Price:

$41.00 USD

Shipping calculated at checkout

Quantity:

Pickup currently unavailable at Bigtent Showroom

RT5R 2 way radio has a U&V frequency band, the frequency range: 144-148MHz & 420-450MHz, almost the configurations can be realized by the walkie talkie, you can program it by yourself without software or cable.

FM Radio: RT5R walkie talkies can be used as a radio, the FM frequency is 65-108MHz. Clearer sound, easy to use, ergonomic design, is suitable for adventure, camping, hiking, and etc.

VOX function: RT5R two way radio has VOX function, press MENU and button 4 to activate and adjust the VOX level, from 1 to 10. Do not with the help of programming software and cable.

Rechargeable walkie talkies: RT5R two way radio is powered by a Li-ion battery, comes with a USB standard battery charger to recharge it, and the battery capacity reaches 1400mAh, can achieve long standby time.

Battery save: The battery of RT5R capacity reaches 1400mAh, but RT5R has 4 battery save levels. Press MENU and button 3 to choose the level of battery save.

Can be used with DC5V power adapter for charging.

DTMF/CTCSS/DCS FM Ham radio
Frequency range: 144-148MHz & 420-450MHz
Two way radio 5W 128CH
Manual programming function
FM radio
VOX function
Alarm function
High/Low Power selectable
Dual Watch/dual reception
Function OFFSET(frequency offset for repeater access)
Battery saving function SAVE
Timer transmission TOT programmable
Scan function
Function Busy Channel Lock BLCLO
Built-in LED flashlight
Programmable by PC

Manual (PDF)

Download the RT5R manual here.

Firmware/ Software

win11-DriverInstaller
RT5_RT5R_RT5RV_programming_software-CAB

Basic Function
Dual band / dual display / dual standby:
A/B band independent operation( UV UU VU VV)
128 groups channels storage: 2 Lithium Metal batteries required. (included)
VFO & Memory channels scan: Emergency Alarm
Time-out Timer (TOT): 0~9 grades VOX selectable
PTT & ANI ID: FM radio and 25 stations storage
Voice companding: 50 CTCSS/105 DCS
High/Low TX power selectable: DTMF function
Wide/Narrow Band(25kHz/12.5kHz): Yes
VOX function: Yes
Busy channel lock-out(BCLO): Yes
Busy lockout function: Yes
Scanning function: Yes
Monitor function: Yes
Time-out Timer (TOT) function: Yes
LCD display: Yes
Dual display: Yes
Battery voltage display function: Yes
Channel name display and editing functions: Yes
Signal strength indicator: Yes
Keypad lock function: Yes
Built-in Led torch: Yes
FM radio: Yes
Wire clone function: Yes
Emergency alarm function: Yes
Low battery alarm: Yes
Power saving function: Yes
Tone end of transmission: Yes
Chinese and English voice prompt: Yes
PC software programmable: Yes

Basic Descriptions
Rated Voltage: 7.4V DC±10%
Output power: 5W
Battery type: Li-ion battery
Channel: 128
Battery capacity: 1400mAh
Working temperature: -20~+50 ℃
Antenna Impedance: 50ohm
Weight: 200g (Not Antenna)
Dimension ( L x W x H ): 110x58x32mm (Not Antenna )

Specification
Frequency range: UHF: 420-450MHz + VHF: 144-148MHz
Frequency stability: ±2.5ppm
High/Low TX power selectable: VHF:5W/1W UHF:4W/1W
Frequency step: 2.5/5/6.25/10/12.5/25kHz
Carrier wave tolerance: 5ppm
Modulation: 16kΦF3E / 11kΦF3E
Max frequency deviation:< 5kHz(Wide) < 2.5kHz(Narrow)
Modulation character: 6 dB per fold frequency patch
Emission current: < 1.6A(5W)
CTCSS / DCS: 0.5±0.1kHz(Wide) 0.3±0.1kHz(Narrow)
Sensitivity: < 0.16 µV(12dB SINAD)
Silent sensitivity: < 0.2 µV
Intermediation Distortion: <10%
Inter modulation: 60dB
Adjacent channel selectivity( wide/narrow ): <-65dB(Wide) <-60dB(Narrow)

In The Box: Portable radio, Antenna, Li-ion battery pack, LI-ion charger, Belt clip, Sling, User Manual
