[RT87] IP67 Dual Band Business Two Way Radios

Retevis

[RT87] IP67 Dual Band Business Two Way Radios

Name: [RT87] IP67 Dual Band Business Two Way Radios
Brand: Retevis
SKU: A9137A
Price: 92.0 CAD
Availability: InStock

SKU: A9137A

$92.00 CAD

IP67 dustproof and waterproof two way radios. Fearless of dust and Rainstorm.
Remote kill/stun/activate, allowing you to manage the two way radios remotely.
Supports the use of a repeater.
The VHF+UHF frequency band can be used with more commercial radios and users.

Features

IP67 dustproof and waterproof / Dual band (VHF&UHF) / 128 channel,25FM radio channel / FM radio / VOX function / Scan function / Roger beep / Emergency alarm / Battery show / CTCSS/DCS / MSK/DTMF/2T/5T / PTT ID / Compandor / Stun ,Kill, Activate

Manual (PDF)

Download the RT87 manual here.

Firmware/ Software

RT87_softwareV1-0-2
USB-universal-Driver

📌[PLEASE NOTE] Shipping times for pre-orders can vary depending on the product. We'll send you shipping confirmation email as soon as we have the shipping details sorted out!

Quantity:

Retevis [RT87] IP67 Dual Band Business Two Way Radios

$92.00 CAD

[RT87] IP67 Dual Band Business Two Way Radios

Specifications

Dimensions & Weights

General
Frequency:
VHF:136-174MHz
UHF:400-480MHz
Channel capacity: 128
Operating Voltage: DC7.2V(Li-ion)
Frequency Stability: ±2.5ppm
Antenna impedance: 50 Ω
Size(with battery, without antenna): 114x54x32mm/4.89x2.13x1.26in
Weight (with battery and antenna): 194g/6.84oz

Transmitter
Output power: H≥4W L≥1W
Modulation mode: 16KF¢3E/11K¢F3E
Maximum deviation: ≤5KHz/≤2.5KHz
Adjacent Ch Power: ≤－65dB/≤－60dB
Spurious radiation: ≤7uW
Pre-emphasis characteristics: 6dB
Current: ≤1.6A
CTCSS-DCS Deviation: 0.5KHz±0.2KHz,0.4KHz±0.2KHz
Intermediation Sensitivity: 5-12mV
Intermediation distortion: <5％

Receiver
RF Sensitivity: –122dBm (12dB SINAD)
Audio power: 1W
Audio distortion: <5％
Blocking: ≥85
Intermediation: ≥60dB ≥55dB
Selectivity: ≥65dB ≥60dB
Spurious Rejection: ≥60dB

Device

Frequency:
VHF:136-174MHz
UHF:400-480MHz
Channel capacity: 128
Operating Voltage: DC7.2V(Li-ion)
Frequency Stability: ±2.5ppm
Antenna impedance: 50 Ω
Size(with battery, without antenna): 114x54x32mm/4.89x2.13x1.26in
Weight (with battery and antenna): 194g/6.84oz

Transmitter

Output power: H≥4W L≥1W
Modulation mode: 16KF¢3E/11K¢F3E
Maximum deviation: ≤5KHz/≤2.5KHz
Adjacent Ch Power: ≤－65dB/≤－60dB
Spurious radiation: ≤7uW
Pre-emphasis characteristics: 6dB
Current: ≤1.6A
CTCSS-DCS Deviation: 0.5KHz±0.2KHz,0.4KHz±0.2KHz
Intermediation Sensitivity: 5-12mV
Intermediation distortion: <5％

Receiver

RETREVISShareFileEditViewInsertFormatDataToolsExtensionsHelp$%123Default (Arial)1 of 1I8 Applications Model RETEVIS: H-777/RT21/RT22/RT-5R/RT-5RV/H-777S/RT1/RT2/RT5/RT7/RT15/RT17/RT18/RT19/ RT23/RT26/RT27/RT28/RT43/RT46/RT50/RT67/RT68/RT80/RT81 FIT KENWOOD: TH-F6/F6A/D7/D7A/D7AG/D7E/F7/F7E/G71/G71A, TH-G71E/K2/K2A/K2E/K2ET/21/21AT/21BT/22, TH-22A/22AT/22E/25/26/27/28/31AT/31BT/41AT/41BT, TH-42/42A/42AT/2E/45/46/47/48/55/75/77/G71, TH-205/-215/225/235/235A/235E/315/41, TK-208/220/240/240D/248/250/260/260G/270/270G/308, TK-360G/370/370G/372G/373G/320/340/340D/348/350, TK-378/378G/430/431/353/360, TK-2100/ 2102/2130/ 2160/3100/3101/3102/3107/ , TK-3118/3130/3131/3160 etc BAOFENG: UV-5R Series, BF-F8HP,UV-82 Series,UV-82C,UV-82H,BF-480/490/320/V6/520/530/999/888/666S/BF-888S and more FIT HYT: TC286 386 2685 3865 6685/TC 278 378 388 FIT LINTON: LT-2288/3288/6288/5288/3188/2188/3260/2268/3268,/6288/6188/3288ASheet1RF Sensitivity: –122dBm (12dB SINAD)
Audio power: 1W
Audio distortion: <5％
Blocking: ≥85
Intermediation: ≥60dB ≥55dB
Selectivity: ≥65dB ≥60dB
Spurious Rejection: ≥60dBTurn on screen reader supportTo enable screen reader support, press Ctrl+Alt+Z To learn about keyboard shortcuts, press Ctrl+slashTablesStart with pre-built tablesIncludes smart chips, placeholders, and custom color palettesFeaturedEvent tasksProject tasksContent trackerProduct prioritizationRecruitment applicantsEvent planningCustomer relationsProject managementTravel plannerProduct roadmapInventory managementRecruitmentTeam plannerMarketing

[RT87] IP67 Dual Band Business Two Way Radios

Features

Manual (PDF)

Firmware/ Software

📌[PLEASE NOTE] Shipping times for pre-orders can vary depending on the product. We'll send you shipping confirmation email as soon as we have the shipping details sorted out!

Specifications

Customer Reviews
