[RT87] IP67 Dual Band Business Two Way Radios

Roll over image to zoom in Click on image to zoom

[RT87] IP67 Dual Band Business Two Way Radios

Name: [RT87] IP67 Dual Band Business Two Way Radios
Brand: Retevis
SKU: A9137A
Price: 70.0 USD
Availability: OutOfStock

RetevisSKU: A9137A

Price:

$70.00 USD

Shipping calculated at checkout

Quantity:

Pickup currently unavailable at Bigtent Showroom

IP67 dustproof and waterproof two way radios. Fearless of dust and Rainstorm.
Remote kill/stun/activate, allowing you to manage the two way radios remotely.
Supports the use of a repeater.
The VHF+UHF frequency band can be used with more commercial radios and users.

IP67 dustproof and waterproof
Dual band (VHF&UHF)
128 channel,25FM radio channel
FM radio
VOX function
Scan function
Roger beep
Emergency alarm
Battery show
CTCSS/DCS
MSK/DTMF/2T/5T
PTT ID
Compandor
Stun ,Kill, Activate

Manual (PDF)

Download the RT87 manual here.

Firmware/ Software

RT87_softwareV1-0-2
USB-universal-Driver

General
Frequency:
VHF:136-174MHz
UHF:400-480MHz
Channel capacity: 128
Operating Voltage: DC7.2V(Li-ion)
Frequency Stability: ±2.5ppm
Antenna impedance: 50 Ω
Size(with battery, without antenna): 114x54x32mm/4.89x2.13x1.26in
Weight (with battery and antenna): 194g/6.84oz

Transmitter
Output power: H≥4W L≥1W
Modulation mode: 16KF¢3E/11K¢F3E
Maximum deviation: ≤5KHz/≤2.5KHz
Adjacent Ch Power: ≤－65dB/≤－60dB
Spurious radiation: ≤7uW
Pre-emphasis characteristics: 6dB
Current: ≤1.6A
CTCSS-DCS Deviation: 0.5KHz±0.2KHz,0.4KHz±0.2KHz
Intermediation Sensitivity: 5-12mV
Intermediation distortion: <5％

Receiver
RF Sensitivity: –122dBm (12dB SINAD)
Audio power: 1W
Audio distortion: <5％
Blocking: ≥85
Intermediation: ≥60dB ≥55dB
Selectivity: ≥65dB ≥60dB
Spurious Rejection: ≥60dB
