Toyota Tacoma Prinsu Cab Rack (2005-2021)
Product powder coated in a satin black texture
Noise reducing edge trim is included with the roof rack purchase.
The Tacoma Cab Rack is a modular, adjustable, and completely bolt together roof rack for 2005-2019 Toyota Tacoma in the double cab configuration. See also our model for the access cab configuration.
The rack consists of 2 laser cut side rails constructed of 3/16″ 5052 aluminum plate. These rails have 3 mounting tabs each that will allow you to bolt the rack into the 5 factory mounting holes on each side of the roof. This design allows the addition of this roof rack without drilling or modification to your vehicle.
The crossbars are made from a 2″ x 1″ aluminum extrusion that has a top facing T-slot channel. This offers numerous solutions for tie-down options, cargo security, and the addition of accessories such as tool mounts or lighting.
All product will come in black. All assembly hardware comes in a black zinc finish so as to match a black paint or powder coat finish on the final product. The rack also includes a 1/8″ 5052 aluminum plate wind deflector to help with aerodynamics and prevent wind noise. Options for integrating a light bar are available.
The rack is completely modular in that you choose how your rack is configured. Refer to the gallery for an example of standard configurations we have used based on different load sizes and weights. You can also choose the number of crossbars you assemble your rack with. The rack comes standard with 6 cross bars for cargo and 1 additional for mounting of a wind deflector, lightbar or combination of the two.
Weight capacity of the racks varies based on the number of crossbars used and their configuration. We expect all consumers to use good judgment and common sense with the loads they plan to carry using these rack systems.
- Year Range: 2005-2021
- Make: Toyota
- Model: Tacoma
Tacoma Cab Rack (2005-2019)
- Weight: 22.67 kg / 50 lbs
- Dimensions: 203.2 x 20.32 x 20.32 cm / 80 x 8 x 8 inch
- Wind Deflector Type: Cutout for 40inch Lightbars, Standard
Light Bar Mount
- Weight: 0.45 kg / 1 lbs
- Dimensions: 2.54 x 2.54 x 2.54 cm / 1 x 1 x 1 inch
